NSK 100BNR10STDUELP4Y Ultra High - Speed Spindle Bearings (Set of Two) For Sale

When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.

---

NSK 100BNR10STDUELP4Y Ultra High - Speed Spindle Bearings (Set of Two):
$540.00

NSK 100BNR10STDUELP4Y SUPER PRECISION, ULTRA HIGH - SPEED SPINDLE BEARINGS; DUPLEX SET.

Brand: NSK

Nominal bearing bore 100 Bore diameter (mm)

Bearing typeBNR: 18 Degree Contact angle

Dimension10: 10 Series

Boundary Dimensions 100mmx 150mm x 24mm

Material S: Rolling elements (Bearing steel SUL2)Ring (Bearing steel SUL2)

Cage T: Phenolic resin case

ArrangementDU: Universal arrangement (double row)

Preload EL: Extra light

Accuracy P4Y: Special accuracy (Bore and outside diameter exclusiveto NSK.

Equivalent to ISO Class 4 ABEC – 7)

Limiting speeds Grease:11,200 r/min Oil: 16,000 r/min

Static load rating CO: 36 kN

Dynamic load rating C: 36 kN

Quantity Two bearings

Made in Japan by NSK ltd.

---

---

---
