Cognex, Barcode Reader/Scanner, DataMan ODDM-3XT-625, 821-10028-2R:
$150.00

Cognex DataMan Barcode Reader/Scanner – DataMan 470 Series – 821-10028-2R

This is a Cognex DataMan industrial fixed-mount barcode reader, part number 821-10028-2R, designed for automated barcode and machine-vision applications in industrial production, manufacturing, inspection, tracking, and material-handling environments.

The 821-10028-2R is associated with the Cognex DataMan 470 Series, including the DM474X/DM474X-M configuration. It is a high-performance industrial vision-based barcode reader intended to be mounted in a fixed position and integrated into an automated system. Various listings identify this part number as a DM474X-series reader and show it configured with a lens and industrial lighting.

Product Features

Manufacturer: Cognex
Product family: DataMan 470 Series
Model/configuration: DM474X / DM474X-M
Part Number: 821-10028-2R
Type: Fixed-mount industrial barcode reader/scanner
Application: Automated barcode reading and machine-vision inspection
Configuration: Reader with lens/optical assembly
Industrial design: Intended for integration into automated production and inspection equipment
High-resolution imaging: The DM474X-M configuration has been listed with a 2048 × 1536 image sensor and approximately 1475 mm focus distance, depending on the specific optical configuration.

Industrial Applications

The Cognex DataMan 470 series is suited for applications where reliable, automated identification of products, packages, components, or other items is required. Typical uses include:

Manufacturing and production lines
Automated material tracking
Product identification
Packaging and labeling verification
Parts traceability
Logistics and warehouse automation
Machine-vision systems
Automated inspection stations
Conveyor-based barcode reading
Industrial quality-control systems

The fixed-mount design allows the reader to be positioned over a conveyor, workstation, production cell, or inspection area and integrated into a larger automated system.

Optical and Lighting Configuration

The 821-10028-2R part number is documented by industrial automation suppliers as a DataMan 470-series configuration supplied with an optical lens. Some references also associate the part with Cognex industrial lighting configurations. Because the exact lens, lighting, and revision can vary between units, buyers should compare the markings and photographs of the specific unit being purchased with their existing equipment before ordering.

Electrical Information

Available industrial-parts documentation lists the associated unit with the following electrical requirements:

Input: 24 VDC, up to 1.5 A
Light output: 24 VDC, up to 0.75 A

These ratings should be verified against the identification label and documentation for the exact hardware revision before installation.

Condition / Compatibility

This is an industrial automation component intended for professional equipment and system integration. The exact condition, included accessories, cables, mounting hardware, lens configuration, and firmware/software version can vary depending on the individual unit.

Please verify the part number, model number, connector configuration, lens/lighting arrangement, and revision shown on the actual unit before purchasing to ensure compatibility with your application.

The manufacturer part number 821-10028-2R is also listed by some industrial suppliers as discontinued, although new-surplus, used, and refurbished units remain available through the secondary market.

Part Number Identification

Cognex 821-10028-2R / 821100282R

This part number may appear in listings under related descriptions such as:
