On eBay Now...New Belimo AFB24-SR Spring Return Actuator 180 IN/LB 24V AC/DC 5.5W AFB24SR USA For Sale
When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.
New Belimo AFB24-SR Spring Return Actuator 180 IN/LB 24V AC/DC 5.5W AFB24SR USA:
$206.28
Specifications
Voltage AC/DC AC/DC 24 V
Power Consumption (Running) 5.5 W
Power Consumption (Holding) 3 W
Power Consumption For Wire Sizing 8.5 VA
Torque 180 in-lb [20 Nm]
Control Type DC 2...10 V
Direction Of Motion Motor selectable with switch 0/1
Direction of Rotation (Fail-Safe) Reversible with cw/ccw mounting
Manual Override 5 mm hex crank (3/16" Allen), supplied
Angle of Rotation 95°
Running Time (Motor) 95 s / 90°
Running Time (Fail-safe) <20 s
Degree Of Protection NEMA NEMA 2Enclosure
Type UL Enclosure Type 2Ambient Temperature -22...122°F [-30...50°C]
Belimo AFB24-SR Spring Return Damper Actuator - Orange NEW
$225.00
New Belimo B238+AFRX24-MFT Characterized Control Valve
$250.00
Brand New BELIMO GMB24-SR ACTUATOR 24VAC/DC 360 in-lb/ 40Nm
$297.50
