8V-36V to 10A 120W Car Power supply regulator module 12V to 12V waterproof For Sale

When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.

---

8V-36V to 10A 120W Car Power supply regulator module 12V to 12V waterproof:
$53.13

Model: WG8-36S1210L

• Input voltage: 12V/24V DC
• Input voltage range: 8-36V DC
• Conversion efficiency: >96%
• Output voltage: 12V
• Output current: 10A
• Output rated power: 120W
• Output peak power: 125%
• Voltage regulation rate: < 1%
• Load adjustment rate: < 2%
• No-load current: < 58mA
• Ripple: < 160mV
• Operating temperature: -35 ° C to +50 ° C
• Waterproof rating: IP68
• Overcurrent protection: YES
• Overvoltage protection: YES
• Over temperature protection: YES
• Short circuit protection: YES
• Product size: 110*74*23mm
• Product net weight: 250g
• Heat dissipation method: natural heat dissipation in die-cast aluminum housing

Input: red line (+) positive, black line (-) negativeOutput: yellow (white) line (+) positive, black (-) negative

---

---

---
