SealMaster MSF-27T Gold Line 4-Bolt Flange Bearing, 1-11/16" Bore, Cast Iron For Sale

When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.

---

SealMaster MSF-27T Gold Line 4-Bolt Flange Bearing, 1-11/16" Bore, Cast Iron:
$136.00

Sealmaster MSF-27T Gold Line Four-Bolt Flange Ball Bearing Unit - 1-11/16 in Bore, 4-Bolt Flange, Set Screw Locking, Cast Iron Housing Material, Non-Expansion Bearing (Fixed), Medium Duty, Felt Labyrinth Seal Seal

Bolt Size: 0.5625”

Insert #: 3-111T

Bolt Circle Dia.: N/A

Replaceable Insert: Yes

Operating Temperature [Max]: 220 °F

Bolt Hole Spacing: 4 3/8”

Housing Color: Gray

Angle of Misalignment: ±2°

Overall Height (in): 2.21875”

Collar O.D.: 3.25”

Centerline to Front Face (in) : 1.34375”

Mounted Unit Duty: Medium Duty

Inner Race Heat Treat Method: Zone-Hardened

Bore Size: 1.688”

Seal Type: Felt Labyrinth

Internal Clearance: Standard

Outer Ring Land Profile: Standard

Series MSF

Maximum Operating Temperature: 220

Lubrication: Lithium Complex NLGI 2 Grease

Bore Shape: Straight

Speed [Max]: 5000 rpm

Expansion : No

Bearing Design: Non-Expansion

Relubricatable: Yes

Misalignment Type: Static Only

Insert Material: 52100 Bearing Steel, Black Oxided

Housing Base : Solid

End Type: Open End

Retainer Type: Land Riding

Platform: Gold Line Ball Bearing

Bearing Insert Coating: Black Oxide

Locking Device: Skwezloc® Concentric Collar

Bolt Center-to-Center Length: 4.3750”

Duty Series: Medium

Shaft Dia.: 1.6875”

Foot Height: 0.563”

Inner Race Length: 2.094”

Housing Material: Cast Iron

Housing Construction: One Piece

Overall Height: 2.219”

Housing Length: 5 5/8”

Flange Type: 4-Bolt Flange

Foot Height: 0.5625”

Bolt Center-to-Center Length: 4.375”

Inch/Metric: Inch

Bearing Type: Ball Bearing

Inner Race Length: 2.09375”

Centerline to Front Face : 1.344”

End Cap No

Locking Type: Concentric

Pilot Configuration: No Pilot

Collar OD: 3.25”

Weight: 7.065 LB

EAN or UPC: 662461032169

---

---

---

SealMaster MSF-27T Gold Line 4-Bolt Flange Bearing, 1-11/16" Bore, Cast Iron

$136.00

---

Seal Master Bearing MSF-27 New

$130.00

---

SealMaster MSF-19T Flange-Mount Gold Line Bearings Std 1-3/16" F-506 2-17A 3-13T

$100.00

---
